Battery
Six-Bar Linkage Full Suspension
The powerful six-bar linkage rear suspension is a unique technology of Maxfoot. With the use of the six-bar linkage rear suspension and the front fork suspension, you will feel extremely comfortable when riding. It's a true soft-tail electric bicycle.
750W
Rear Hub Motor
85N.m
Motor Torque
48V -14 Ah
Lithium-lon Battery
300 lbs
Payload Capacity
Electronics
Panasonic 48V 14AH Lithium Battery
Hub Motor
750W Brushless Bafang Geared Hub Motor
Throttle
Variable Speed Control - 1/2 Twist Throttle
Display
Maxfoot 5 Inch LCD Display With USB Port
Controller
Maxfoot 25A Overall Waterproof Controller
Integrated Wiring
Water-Resistant Connectors and Wiring Harness
Mechanics
Frame
6061 Aluminium-Alloy Frame
Suspension
Six-Bar Linkage Rear Suspension
Brake Lever
Tektro Mechanical EL555-RT/EL550-RS
Rotors
Tektro 180mm F/R Alloy Disc Brake
Tire
DURABLE 20" x 4.0" Tire
Chain Puller
Shimano M-310 derailleur & 7 Speeds gear
Data
Charging Time
5-6 Hours
N.W:/G.W:
85 lbs / 98 lbs
Range
50-60 Miles with PAS 1
Max. Load Capacity
300 lbs
Battery Life
Rated For 800 Charge Cycles
Frame Size
20"
Appropriate Height
5'2"-6'3"
Size
Handlebar Height
46" - 50" (adjustable)
Handlebar Reach
17"
Seat Height
34.5" - 38" (Measured from bottom of the pedal stroke)
Standover Height
29"
Total Length
72"
Wheelbase
47.5"
Seat Tube Length
16"
Handlebar Width
24"
Crank Length
210 mm
Seatpost Diameter
35 mm
Max Tire Width
4"
Folded Dimensions (LxWxH)
42" x 21" x 32"
